Oil-hydraulic Control Valves
P.IVA: IT00630881209
CONTACTS
AmioleodinamicaAmioleodinamica
| Manufactured in 1 to 10 elements | |
| Nominal flow rate | 70 l/min |
| MAX working pressure | 350 bar |
| MAX return backpressure | 80 bar |
| Standard PRESSURE RELIEF valve, may be set | da 10 a 350 bar |
| Single-acting check valve for each element Negative spool overlapping | |
| Reversing spool for right-hand or left-hand inlet Preset for CARRY-OVER | |
| Working temperature | min.-30°C ÷ max. 80°C |
| MAX spool leakage at 100 bar (Temp. 50°C Visc. 27 CST) | 20 ml/min |
| MODEL | L (MM) | F (MM) | WEIGHT (KG) |
| AMI 42C/1 (1 sections) | 130 | 114 | 8,900 |
| AMI 42C/2 (2 sections) | 175 | 159 | 12,000 |
| AMI 42C/3 (3 sections) | 220 | 204 | 16,900 |
| AMI 42C/4 (4 sections) | 265 | 249 | 20,900 |
| AMI 42C/5 (5 sections) | 310 | 294 | 24,900 |
| AMI 42C/6 (6 sections) | 355 | 339 | 28,900 |
| AMI 42C/7 (7 sections) | 400 | 384 | 32,900 |
| AMI 42C/8 (8 sections) | 445 | 429 | 36,900 |
| AMI 42C/9 (9 sections) | 490 | 474 | 40,900 |
| AMI 42C/10 (10 sections) | 535 | 519 | 44,900 |
| Manufactured in 1 to 10 elements | |
| Nominal flow rate | 70 l/min |
| MAX working pressure | 350 bar |
| MAX return backpressure | 80 bar |
| Standard PRESSURE RELIEF valve, may be set | da 10 a 350 bar |
| Single-acting check valve for each element Negative spool overlapping | |
| Reversing spool for right-hand or left-hand inlet Preset for CARRY-OVER | |
| Working temperature | min.-30°C ÷ max. 80°C |
| MAX spool leakage at 100 bar (Temp. 50°C Visc. 27 CST) | 20 ml/min |
| MODEL | L (MM) | F (MM) | WEIGHT (KG) |
| AMI 42C/1 (1 sections) | 130 | 114 | 8,900 |
| AMI 42C/2 (2 sections) | 175 | 159 | 12,000 |
| AMI 42C/3 (3 sections) | 220 | 204 | 16,900 |
| AMI 42C/4 (4 sections) | 265 | 249 | 20,900 |
| AMI 42C/5 (5 sections) | 310 | 294 | 24,900 |
| AMI 42C/6 (6 sections) | 355 | 339 | 28,900 |
| AMI 42C/7 (7 sections) | 400 | 384 | 32,900 |
| AMI 42C/8 (8 sections) | 445 | 429 | 36,900 |
| AMI 42C/9 (9 sections) | 490 | 474 | 40,900 |
| AMI 42C/10 (10 sections) | 535 | 519 | 44,900 |
